HPC-Inference

Imageomics Logo ABC Logo

HPC-Inference

Batch inference solution for large-scale image datasets on HPC

About

Problem: Many batch inference workflows waste GPU resources due to I/O bottlenecks and sequential processing, leading to poor GPU utilization and longer processing times.

Key Bottlenecks

  • Slow sequential large file loading (Disk → RAM)
  • Single-threaded image preprocessing
  • Data transfer delays (CPU ↔ GPU)
  • GPU idle time waiting for data
  • Sequential output writing

HPC-Inference Solutions

  • Parallel data loading: Eliminates disk I/O bottlenecks with optimized dataset loaders
  • Asynchronous preprocessing: Keeps GPUs fed with continuous data queues
  • SLURM integration: Deploy seamlessly on HPC clusters
  • Multi-GPU distribution: Scales across HPC nodes for maximum throughput
  • Resource profiling: Logs timing metrics and CPU/GPU usage rates to help optimize your configuration

Core Features

Iterative PyTorch Dataset

The hpc_inference package's core functionality includes customized PyTorch datasets:

  • ParquetImageDataset for image data stored as compressed binary columns across multiple large Parquet files
  • ImageFolderDataset for image data stored in folders using open file formats such as JPG, PNG, TIFF, etc.
  • HDF5ImageDataset for streaming image data from HDF5 files with built-in distributed processing support
from pathlib import Path
from hpc_inference.datasets import ParquetImageDataset, ImageFolderDataset, HDF5ImageDataset

# Parquet dataset
parquet_files = list(Path("/path/to/data").glob("*.parquet"))
parquet_dataset = ParquetImageDataset(parquet_files, preprocess=preprocess)

# Image folder dataset
image_folder_dataset = ImageFolderDataset("/path/to/images", preprocess=preprocess)

# HDF5 dataset
hdf5_files = list(Path("/path/to/data").glob("*.h5"))
hdf5_dataset = HDF5ImageDataset(hdf5_files, preprocess=preprocess)

Use with PyTorch DataLoader for batch processing:

from torch.utils.data import DataLoader

loader = DataLoader(hdf5_dataset, batch_size=32, num_workers=4)
for batch_ids, batch_tensors in loader:
    # Process batch
    embeddings = model(batch_tensors.to(device))

Batch Inference Job Scripts

Ready-to-use inference scripts for common tasks:

Task Command Module Description
CLIP Embedding hpc_inference.inference.embed.open_clip_embed Generate embeddings with OpenCLIP models
Face Detection hpc_inference.inference.detection.face_detect Detect faces using YOLO-based models
Animal Detection hpc_inference.inference.detection.animal_detect Wildlife detection with MegaDetector

Basic Usage

python -m hpc_inference.inference.embed.open_clip_embed \
    /path/to/input \
    /path/to/output \
    --input_type parquet \
    --model_name ViT-B-32 \
    --pretrained openai \
    --batch_size 32 \
    --num_workers 8

Config files are recommended for production workflows as they:

  • Keep parameters organized and reproducible
  • Allow easy sharing and version control
  • Reduce command-line complexity
python -m hpc_inference.inference.embed.open_clip_embed \
    /path/to/input /path/to/output \
    --input_type parquet --config config.yaml

Templates

  • Config templates → configs/ (e.g., config_embed_parquet_template.yaml, config_embed_hdf5_template.yaml)
  • SLURM job templates → scripts/ (e.g., open_clip_embed_parquet_template.slurm)

SLURM Integration

The datasets automatically detect SLURM_PROCID and SLURM_NTASKS to distribute files across ranks. Use srun in your SLURM scripts to scale across multiple nodes.

Acknowledgement

This project is a joint effort between the Imageomics Institute and the ABC Global Center.
