Worked Example for Grevy's Zebras Time-Budget Analysis

This session includes two male Grevy's zebras travelling across an open plain on the 18th of January, 2023, between 12:45 and 13:00.

flightpath Figure 1: Flight path (left) tracking 2 male Grevy's zebras observed on 01/18/23. Video clip (right) from KABR dataset.

Step 1: Download raw videos from session 7 on the 18th of January, 2023

You can download the raw videos directly from the KABR Raw Videos dataset.

The videos files are: \ 18_01_18_DJI_0068_trimmed \ 18_01_18_DJI_0069 \ 18_01_18_DJI_0070 \ 18_01_18_DJI_0071

mkdir -p grevystimebudget/raw_videos

cd grevystimebudget/raw_videos

wget https://huggingface.co/datasets/imageomics/KABR-raw-videos/blob/main/18_01_2023_session_7/DJI_0068_trimmed.mp4

wget https://huggingface.co/datasets/imageomics/KABR-raw-videos/blob/main/18_01_2023_session_7/DJI_0069.mp4

wget https://huggingface.co/datasets/imageomics/KABR-raw-videos/blob/main/18_01_2023_session_7/DJI_0070.mp4

wget https://huggingface.co/datasets/imageomics/KABR-raw-videos/blob/main/18_01_2023_session_7/DJI_0071.mp4

cd ../..

Step 2: Extract mini-scenes from raw videos using tracks_extractor

You can download the CVAT annotations for these from the KABR Worked Examples dataset.

The annotations files are:

18_01_2023_session_7-DJI_0068.xml \ 18_01_2023_session_7-DJI_0069.xml \ 18_01_2023_session_7-DJI_0070.xml \ 18_01_2023_session_7-DJI_0071.xml \

mkdir -p grevystimebudget/annotations

cd grevystimebudget/annotations

wget https://huggingface.co/datasets/imageomics/kabr-worked-examples/blob/main/detections/18_01_2023_session_7-DJI_0068.xml

wget https://huggingface.co/datasets/imageomics/kabr-worked-examples/blob/main/detections/18_01_2023_session_7-DJI_0069.xml

wget https://huggingface.co/datasets/imageomics/kabr-worked-examples/blob/main/detections/18_01_2023_session_7-DJI_0070.xml

wget https://huggingface.co/datasets/imageomics/kabr-worked-examples/blob/main/detections/18_01_2023_session_7-DJI_0071.xml
cd ../..

Now you can use the tracks_extractor tool to extract mini-scenes from the raw videos using the CVAT annotations.

mkdir -p grevystimebudget/miniscenes
tracks_extractor --video grevystimebudget/raw_videos --annotation grevystimebudget/annotations --imshow --tracking
This will create a folder called miniscenes in the grevystimebudget directory with the extracted mini-scenes. The --imshow flag will display the mini-scenes as they are being extracted, and the --tracking flag will enable tracking of individuals across frames. This process may take a while depending on the number of videos and annotations.
# Example output:
Processing video: grevystimebudget/raw_videos/18_01_18_DJI_0068.mp4
Extracted 150 mini-scenes from 18_01_18_DJI_0068.mp4

See mini-scenes extracted for this session here: grevystimebudget/miniscenes

Step 3: Label mini-scenes with behavior using miniscene2behavior

You can use the x3d_kabr_kinetics tool to classify behaviors in the extracted mini-scenes.

Download model weights from Hugging Face.

mkdir -p grevystimebudget/classified_behaviors

miniscene2behavior --hub imageomics/x3d-kabr-kinetics --checkpoint x3d_kabr_kinetics.pyth --miniscene grevystimebudget/miniscenes/ --output grevystimebudget/mini_scene_behavior_annotations/DJI_0068_annotations.csv
This will classify the behaviors in the mini-scenes and save the results in a CSV file called DJI_0068_annotations.csv in the /mini_scene_behavior_annotations directory.

See behavior classifications extracted for this session here: grevystimebudget/mini_scene_behavior_annotations

Step 4: Perform Ecological Analysis

We can analyze the behavior annotations labeled in Step 3 to create time budgets for the individuals observed in this session.

See the time budgets notebook for the code to create the visualizations.

Key step: convert the behavior labels generated by the miniscene2behavior to labels using the ethogram used in the field observations.

label2number = {
    "Walk": 0,
    "Graze": 1,
    "Browse": 2,
    "Head Up": 3,
    "Auto-Groom": 4,
    "Trot": 5,
    "Run": 6,
    "Occluded": 7}

Figure 2: Overall time budget for duration of 10 minute observation


Figure 3: Gantt chart for each zebra generated from time budget data (3 minute duration)
